A car is a multifunctional system whereit is important for the coordinated and synchronized work of all mechanisms and each node separately. Various malfunctions and breakdowns of at least one of the details may lead to violations of a clear algorithm for the operation of other systems. It is not uncommon to encounter a situation where the revolutions fall when the brake is pressed. With this trouble, they often turn to auto mechanics. If during the braking suddenly started to swim the speed, do not wait until the car gets up. Soon after this, the engine will begin to vibrate strongly and stall. By the way, the problem is actual only on gasoline engines.

Possible reason

Turns fall when the brake is pressed due to various malfunctions in the vacuum brake booster.When the brake pedal is depressed, the speed dropsTo find out the reason more precisely, it is necessary to know how this node is constructed. Knowing how this amplifier works, and encountering such breakdowns, it will be easier to solve the problem.

Vacuum amplifier

If pressing the brake decreases the speedengine, the fault is the vacuum amplifier or its component parts. Often, this problem happens because of the design features of this mechanism and the principle of its operation. This mechanism is in a round closed case. It is located under the hood, near the brake pedal. The master cylinder is connected to the body. The main task of this unit is to reduce the pressure on the pedal when speed reduction is performed. At the heart of the amplifier is the diaphragm.

Diaphragm

This part is quite flexible and at the same timedurable. It is made of modern polymer materials on a polyurethane basis. In the central part of the diaphragm there is a detail made of steel in the form of a circle, in which two stems rest on opposite sides. One of these elements is connected to the pedal.brake speed drop The second - with the main brake cylinder.The diaphragm divides the body into two parts. One of these parts is vacuum. It is located on the side of the master cylinder. The second is the atmospheric half and is on the other side. The vacuum brake servo is sealed. Its body with a diaphragm inside is rolled. The two halves are connected to each other by means of a working valve. The brake pedal is used as a drive for this valve.

Principle of operation

The main task of the amplifier is to maintain the vacuum intwo communicating chambers at the moment when the valve is open and the brake is not pressed. If you press the pedal, the element closes. In this case, in the part responsible for vacuum, there will be a powerful rarefaction. In order to obtain this rarefaction, a pipeline leading to the intake manifold of the power unit is fed to the choke of the chamber. Also in the design of the mechanism is a return spring.why, when the brake is pressed, the reason It returns the diaphragm to its normal position.When the driver presses the pedal for the first time, the valve closes. If you continue to press, an air hole will appear in the atmospheric chamber and air will enter there. The pressure inside the chamber is 760 mm Hg. Art. Due to dilution, the pressure on the master cylinder rod will increase, and therefore the braking efficiency will increase. This principle of the amplifier is relevant only for gasoline engines. On diesel it is impossible to get a vacuum in this way. Therefore, automakers equip the amplifiers for diesel units with special pumps.

Crankshaft and braking force feedback

As already noted above, the vacuum amplifieris in direct connection with the intake manifold. Therefore, any breach of the seal of the reservoir will adversely affect the quality of the air-fuel mixture that enters the engine cylinders. A mixture of air and fuel, where there is not enough oxygen, will not burn completely. Therefore, the power unit loses power and efficiency.When the brake is applied, the engine speed drops That's why when you press the brake pedal, the rpm falls.

Methods of diagnosis

If there is a problem during the use of the vehiclesimilar problems, it is necessary to find out immediately what exactly are the malfunctions. The fact is that the situation when when the brake is pressed down the speed is very unpleasant. If in the beginning only slightly falls speed, then after a while the engine just stalls with light touch of the brake pedal. This can happen at the most inopportune time. Note that even in a fully serviceable car, the rpm falls when the brake is applied, but this drop is negligible. This happens because of the design of the amplifier.

Hose

When the drop in the number of revolutions is quitethen it is necessary to visually inspect the hose connecting the amplifier and the intake manifold to the engine. If the tube has visible damage, and this can be various cracks or tears, then the integrity of the reservoir is impaired. What in the end? The process of the normal preparation of the fuel mixture is changing, which is why the stable operation of the engine is disturbed. That's why when you press the brake pedal, the speed drops and the engine stalls.When the brake is applied, the speed drops If there is damage to the hose, it is recommendedreplace it. And then the problem will be solved. If the tube is ideal, you should look for air sucking in the manifolds and in the vacuum amplifier itself. If this does not help to solve the problem, then the reason is worth searching in the amplifier itself. But it must be remembered that it will not be possible to repair the vacuum mechanism of the braking force. It is non-repairable, and therefore the issue can only be solved by a complete replacement.

Typical vacuum amplifier faults

Before talking about the malfunctions of thissystem, it should be noted that the failure of the mechanism does not completely disable the system. The brakes will work, but to drive a car with a faulty amplifier, you will have to apply more effort to reduce the speed.why when the brake pedal is depressed In this case, when you press the brake, they fallturns. One of the most popular breakages is the rupture of the hose. From under the hood, you will hear a characteristic hiss. What to do in this case, has already been said above. Also, breakdowns inside the amplifier mechanism are possible. The valve may be damaged. During operation, it hardens, and due to the wear of the rubber, the diaphragm and the elastic partition can collapse.

Diagnosis of the vacuum amplifier

So, if you notice a drop in speed by pressingon the brake, then first thing is to check the amplifier for serviceability. Of course, you can go to a specialist in carburettors. But the problem of the fall in turnover is unlikely to be solved. If there is a depressurization, this will result in air entering the intake manifold. As a result, the turns fall when the brake is pressed. The fuel-air mixture is sharply impoverished. There is also another way to diagnose. The brake pedal is pressed up to six times on the muffled engine. Then the pedal is fixed in the middle position and the motor is turned on.Turns fall when you press the brake When the pedal goes down in the processstart, then the amplifier is all right. If it remains in the same position, it is necessary to pay special attention to the element. At visual inspection it is necessary to search for stains on the case and the reason for streaks.

Replacement of the vacuum amplifier

To replace this mechanism is sufficientjust by having the right tool. In various cars, it may be necessary to dismantle the expansion tanks. During the operation, remove the brake cylinder, and then the amplifier itself. In terms of time it takes about three hours.

Summary

Vacuum amplifier is an important thing to do in anycar. He makes the braking process easy and at ease. That's why when you press the brake, the rpm falls. The reason is in a faulty amplifier or system leakage.
